Brushless Ebike Motor Controller 72v 80a Sine Wave Dual Mode Electric Bike

Ebike Controller 48-72V 80A Sine Wave Controller Dual Mode

Features:

  • Speed Limit ( will limit the speed to around 15.5 mph)
  • Fast self-learning mode: quickly match all kinds of motors
  • Smart Controller (can be used with any batteries)
    from 48v(13s) Less Speed
    up to 72V (20s) More Speed

Specifications:

  • Protocol: No.2 (LCD: SW900 / UKC1(omd) / M8 / S866 / EN06)
  • Controller Type:
    • Sine Wave (default)
    • Dual Mode (disconnect the hall plug and will work in sensorless mode, handy when hall sensors are broken or motor cable damaged)
  • Rated Voltage: DC 48-72V
  • Power Output:
    • 48V- 3800W
    • 52V-4100W
    • 60V-4820W
    • 72V-5700W
  • Motor Compatibility: 3000W
  • Maximum Current: 80±1A
  • Rated Current: 40A
  • MOSFETs: 18 high-efficiency MOSFETs
  • Size:22x11x5cm
  • Weight: 1000g approx
  • Cable Length: 13–18 cm
  • Battery Plug:  Rings
  • Motor Phase Plug: Rings

Package Included

    • 1x  48-72V 80A MQ Controller
    $97.95

    Original: $279.87

    -65%
    Brushless Ebike Motor Controller 72v 80a Sine Wave Dual Mode Electric Bike—

    $279.87

    $97.95
